Epoxy Transformer Bushings

Transformer Bushings



Epoxy Transformer Bushings are manufactured to the highest quality standards. Our products are cost effective and our pricing is based on volume. Transformer bushings are available for both indoor and outdoor service.

Standard air to air bushings, used as electrical component connections, are also available and we are able to manufacture custom cast components utilizing epoxy tooling.

We would be pleased to quote new requirements for custom designed epoxy or polyurethane transformer components. Many of the items listed below are standard electrical supplies and are available from stock or with a short lead time.



Epoxy Transformer Bushing 85-275

Low Voltage

Voltage class: 1.2 KV
Tank opening: 2.56"
BIL: 30kv
Current rating: 600-3000 AMPS



Epoxy Transformer Bushing 90-333

Low Voltage

Voltage class: 2.5 KV
Tank opening: 3.06"
BIL: 45kv
Current rating: 2200-6500 AMPS

Epoxy Transformer Bushing 85-412c16ID

Low Voltage

Voltage class: 2.5 KV
Tank opening: 3.06"
BIL: 45kv
Current rating: 2200-6500 AMPS

Epoxy Transformer Bushing 85-411c12ID

Low Voltage

Voltage class: 2.5 KV
Tank opening: 3.06"
BIL: 45kv
Current rating: 2200-6500 AMPS

Epoxy Transformer Bushing 85-410c08ID

Low Voltage

Voltage class: 2.5 KV
Tank opening: 3.06"
BIL: 45kv
Current rating: 2200-6500 AMPS
